A 5CCT surface mount light fixture is a versatile lighting solution that allows for adjustable color temperature settings, typically ranging from warm white to cool white. This feature enables the user to customize the ambiance of a space according to preference or need, making it ideal for various applications including residential, commercial, and retail environments. The “5CCT” refers to the five selectable correlated color temperature (CCT) options that the fixture can provide, offering flexibility in lighting design and application.
FINISH
Black
White
Silvery
CERTIFICATIONS
FEATURES
Parameter
- Housing Material
- Aluminium
- Housing Color
- White/Black
- Rated Input
- 30 W
- Rated Input Voltage
- 120 V
- Frequency
- 50 / 60 Hz
- Light Source
- Light source not changeable
- Light Source
- LED
- Luminous Efficiency
- 90 lm/W
- Light Distribution
- Symmetric
- Colour Consistency
- 5 SDCM
- Switching Cycles
- 25000 h
- Swivel Angle
- 90°
- Toolless Assembly
- Yes
- Product weight
- 500 g
- Connection Type
- Clamp
- Primary Connection
- Connection box IP20
- Power Supply Unit incl.
- Yes
- Power Consumption
- 30 kWh/1000h
- Inrush Current max.
- 5 A / 100 µs
- Power Factor
- 0.90
- Working Temperature
- -20 to 40 °C
- Storage Temperature
- -20 to 40 °C
- Mounting Type
- Surface mount
- Mounting Location
- Inside
- IP Protection Class
- IP 20
- Life Time L70 / B50
- 50000 h
- Energy efficiency class
- E
- Mounting Area
- Ceiling installation
- Control
- SCR dimming
- Control
- 0~10V
- Dimmable
- Yes
- Motion Detector
- No
- Through Wiring possible
- Yes
- Power Supply Unit Changeable
- Yes by technician
- Protection Class
- Protection class II
- Lightcolor
- Warm white (WW)
- Color Temperature
- 2700K/3000K3500K/4000K/5000K
- Colour Rendering Index (Ra)
- 90
- Rated Luminous Flux
- 2700 lm
- Light direction
- Below
- Rated Angle of Reflection
- 25°/45°/60°
- Turning and Swiveling Range
- Swiveling
- Height
- 7.08"
- Diameter
- 3.5"
- Cut Out Diameter
- /
- Mounting Surface Thickness
- /
Featues
● Available in monochromatic high light efficiency and dual color temperature options.
● Uniform light output of the lens.
● CRI greater than 90 indicates.
● Compatible with Thyristor or 0-10V dimming.
● Complimentary Samples Available.
● 5-Year Warranty Assurance.
